Tech-Air 5 is a slim, self-contained wearable airbag vest designed to be worn under virtually any jacket. The system provides unrivaled upper body protection uniquely covering the rider's shoulders, critical in motorcycling accidents, in addition to the chest, ribs and full back. The Tech-Air 5 Airbag System offers the most comprehensive coverage of any motorcycling airbag available today.
The state-of-the-art Tech-Air 5 System features six integrated sensors (3 gyroscopes and 3 accelerometers) to continuously monitor the rider’s position. An algorithm developed closely with MotoGP race data and data from over 2,000 lab-simulated crash scenarios determine when and how the system deploys. The airbag has a maximum inflation time of up to 40ms (or less, depending on vest size). The impact absorption while wearing the airbag results in a decrease of impact force by up to 95% compared to a passive chest or back protector. Inflation time is quick enough to deploy the airbag before the rider's first impact with an obstacle. In addition, the vest will protect stationary riders in the event of a rear-end collision.
The airbag has a battery life good for 30 hours of riding time on a single charge, and an LED display conveniently shows system status directly on the garment. The system features Bluetooth connectivity to pair with the Tech-Air App, which uses the rider’s phone to display the system’s operational status, battery status and provide detailed analysis of a ride. Over-the-air firmware updates are also handled through the app. Alpinestars includes a micro USB charger for quick recharging.
Electronics System:
Airbag System:
Operation:
Notes:
(1) The Tech-Air 5 wearable vest is designed to be worn under any proper fitting textile jacket, keeping in mind that the jacket must be large enough to accommodate the expansion of the airbag in the event of a crash. For textile jackets this requires an additional 4 cm of space around the circumference of the body. For those riders who want to wear a sports leather jacket, Tech-Air 5 may also be worn with Tech-Air compatible leather jackets which have built in leather expansion panels to accommodate the inflation of the airbag. Riders who wish to wear a leather jacket that is not Tech-Air compatible must be sure that the leather jacket has an additional 4 cm of space around the circumference of the entire chest.
(2) The Tech-Air 5 airbag system offers the same protection as that provided by 18 CE Level 1 back protectors, as verified by SGS, an Official CE Certification company, that provides independent testing of product conformity with European Personal Protection Regulations
